| AC input voltage range |
115 / 230VAC by switch |
|---|---|
| AC inrush current (max.) |
Cold start, 60A at 230VAC |
| DC adjustment range |
±10% by potentiometer |
| Overload protection Range |
110%~140% |
| Over voltage protection Range |
115%~145% rated output voltage |
| Withstand voltage |
I/P-O/P: 3.75kVAC, I/P-FG: 2kVAC, O/P-FG: 1.25kVAC |
| Working temperature |
-30~+70°C (refer to output derating curve) |
Features :-
- AC input range selectable by switch
- Withstand 300VAC surge input for 5 second
- No load power consumption<0.5W
- Miniature size and 1U low profile
- High operating temperature up to 70°C
- Protections: Short circuit/Overload/Over voltage/Over temperature
- Cooling by free air convection
- Compliance to IEC/EN 60335-1(PD3)and IEC/EN61558-1, 2-16 for household appliances
- Operating altitude up to 5000 meters
- Withstand 5G vibration test
- High efficiency, long life and high reliability
- LED indicator for power on
- 100% full load burn-in test
- 3 years warranty
