LWC- GSM-SCREW – 06 Screw Base Mount Antenna

This is Screw Base Dual-Band Mount Antenna having a frequency of 824 – 960 MHz & 1710 – 2170 MHz and gain of 4/6 dBi. This antenna is supported to GSM FCT and other GSM Module/Modems. The biggest advantage to dual-band antennas is their ability to provide a strong, stable wireless connection is often difficult to reach locations. For this reason, they are often used in devices such as cellular or dual-band wireless access points.

15 People watching this product now!

6000 +

Products

10:00am - 7pm

Working Hours

Genuine Products

Guaranteed

Description

  1. Frequency (MHz) 824 – 960 MHz & 1710 – 2170 MHz
  2. Gain :4 / 6 dBi
  3. Connector: SMA- Male
  4. Impedance (Ω): 50
  5. VSWR: < 2.0
  6. Cable Length: 3 meter
  7. Base type: Screw Fitting
  8. Compact Size
  9. Low Cost
  10. SMA Male
Additional information
GAIN

4 / 6 dBi

HPBW

H: 3600 ; V: 300 / 400

OPERATIONAL TEMPERATURE

-30° to 60° C

DIMENSION (MM)

280 x φ27
