HC-05 6pin Bluetooth Module with Button

Name: HC-05 6pin Bluetooth Module with Button
SKU: HW-A35
Availability: InStock

SKU: HW-A35

HC-05 6 Pin Wireless Serial Bluetooth Module is a Bluetooth module for use with any microcontroller. It uses the UART protocol to make it easy to send and receive data wirelessly.

The HC-06 module is a slave only device. This means that it can connect to most phones and computers with Bluetooth but it cannot connect to another slave-only device such as keyboards and other HC-06 modules. To connect with other slave devices a master module would be necessary such as the HC-05 version which can do both master and slave.

Add to wishlist

Compare

17 People watching this product now!

6000 +

Products

10:00am - 7pm

Working Hours

Genuine Products

Guaranteed

Description

Working current: matching for 30 mA, matching the communication for 8 mA.
Dormancy current: no dormancy.
Used for a GPS navigation system, water, and electricity gas meter reading system.
With the computer and Bluetooth adapter, PDA, seamless connection equipment.
Bluetooth module HC-08 Master and slave Two in one module.
Use the CSR mainstream Bluetooth chip, Bluetooth V2.0 protocol standards.
Potter default rate of 9600, the user can be set up.
Bluetooth protocol: Bluetooth Specification v2.0+EDR
Speed: Asynchronous: 2.1Mbps(Max) / 160 kbps, Synchronous: 1Mbps/1Mbps.
Security: Authentication and encryption.
Profiles: Bluetooth serial port.
